12-stage reactive power controller with LED display

12-stage single-phase connection reactive power controller for reactive power control in networks with symmetrical loads (TENSE)

The RGM-12S reactive power controller is designed to reduce inductive power drawn from the grid, not from loads. When inductive reactive power is drawn from the grid, it intervenes by activating the capacitors with the appropriate value. In this way, it attempts to bring the cos fi value to the desired level.

• 7 Different programs for power factor compensation

• Manual reactive power compensation programs

• Can only compensate inductive systems

• Automatic step measurement

• Stage drive, release and discharge times are adjustable

• Adjustable harmonic alarm values ​​of voltage and current

• Alarm values ​​for over- and undercompensation adjustable

• Alarm output for voltage, harmonic voltage/current, over- and undercompensation

• Voltage, current and frequency values ​​can be monitored

• Active power, reactive power and apparent power can be monitored

• Monitoring of up to 15th harmonic THD-I

• Monitoring up to the 15th harmonic THD-V possible

• Cosine value can be monitored

• Power factor value can be monitored

• Automatic fan outlet

• Uniform aging in stages (in some compensation programs)
